Technische specificatie van een landbouwtrekker Belarus 1522/1523/1523.3/1523.4/2022.3/2022.4:
Advertentie
Model | Belarus 1522 | Belarus 1523 | Belarus 1523.3 | Belarus 1523.4 | Belarus 2022.3 | Belarus 2022.4 |
Jaren van productie | 1999- | 2004- | 2006- | 2007- | 2006- | 2010- |
Motormodel / type | D-260.1 | D-260.1 | D-260.1S2 | TCD | D-260.4S2 | TCD 2013 L06 2V |
Aantal cilinders / turbocompressor | 6T | 6T | 6TI | 6TI | 6TI | 6TI |
Cilinderinhoud (cm3) | 7120 | 7120 | 7120 | 6057 | 7120 | 7146 |
Zuigerafmeting / slag (mm) | 110×125 | 110×125 | 110×125 | 101×126 | 110×125 | 108×130 |
Maximaal motorvermogen (pk) / tpm | 155/2100 | 155/2100 | 158/2100 | 155/2100 | 212/2100 | 225/2100 |
Koppel (Nm) / tpm | 597/1400 | 597/1400 | 597/1600 | 680/1400 | 900/1400 | 900/1400 |
Aantal versnellingen (voor + achter) | 16+8 | 16+8 | 16+8 | 16+8 | 24+12 | 24+12 |
Aantal gesynchroniseerde versnellingen (voor + achter) | – | – | – | – | – | – |
Advertentie
Speed-Shift | – | – | – | – | – | – |
Type achteruit | – | – | – | – | – | – |
Rijsnelheid (km / u) | 33 | 40 | 40 | 40 | 40 | 40 |
Max. Rijsnelheid (km / u) | – | – | – | – | – | – |
Hydraulische pompcapaciteit (L / min) | 60 | 60 | 55 | 55 | 55 | 55 |
3-punts hefinrichting | ehr | ehr | ehr | ehr | ehr | ehr |
Max. Belasting 3-puntshefinrichting (kg) | 7000 | 7000 | 6500 | 6500 | 6500 | 6500 |
Aftakastoerental (tpm) | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 |
Type schijfrem (droog / nat) | – | – | – | – | – | – |
Type bediening van het remsysteem | – | – | – | – | – | – |
Draaistraal 2WD (m) | – | – | – | – | – | – |
Draaistraal 4WD (m) | 11 | 11 | 11 | 11 | 11,6 | 11,6 |
Advertentie
Voorwiel 2WD | – | – | – | – | – | – |
Voorwiel 4WD | 14.9R24 | 420/70R24 | 420/70R24 | 420/70R24 | 420/70R24 | 420/70R24 |
Achterwiel 2WD | – | – | – | – | – | – |
Achterwiel 4WD | 18.4R38 | 520/70R38 | 520/70R38 | 520/70R38 | 580/70R42 | 580/70R42 |
Totaalgewicht 2WD (kg) | – | – | – | – | – | – |
Totaalgewicht 4WD (kg) | 6000 | 6000 | 6000 | 6500 | 7220 | 7220 |
Totale hoogte met cabine (cm) | 300 | 300 | 300 | 300 | 312 | 312 |
Totale lengte (cm) | 475 | 475 | 464 | 471 | 523 | 523 |
Totale breedte (cm) | 285 | 285 | 276 | 276 | 292 | 292 |
Inhoud brandstoftank (l) | 250 | 250 | 250 | 250 | 357 | 370 |
Geluidsniveau cabine (dB) | 83 | 83 | 83 | 83 | – | – |
